Renogy Core Mini 12V 200Ah LiFePO4 Deep Cycle Battery – Compact Cold-Weather Lithium Power
Renogy Core Mini 12V 200Ah LiFePO4 Deep Cycle Battery – Compact Cold-Weather Lithium Power
Regular price
$696.00 CAD
Regular price
$1,071.00 CAD
Sale price
$696.00 CAD
Quantity
Couldn't load pickup availability
DESCRIPTION
The Renogy Core Mini 12V 200Ah LiFePO4 Battery delivers compact, high-capacity off-grid power designed for RVs, vans, marine systems, and solar storage. With a space-saving design, strong cold-weather performance, and long cycle life, it provides reliable energy in demanding environments. Built with smart BMS protection and high output capability, it ensures stable, maintenance-free power wherever you go.
KEY FEATURES
- Compact High Capacity: 200Ah (2560Wh) usable energy in a space-saving design
- Cold Weather Ready: Operates down to -4°F with low-temperature charging protection
- Long Cycle Life: 5,000+ cycles at 80% DOD for long-term reliability
- Smart 200A BMS Protection: 25+ safety protections for secure operation
- High Output Performance: 200A continuous and up to 380A peak discharge
SPECIFICATIONS
- Product Name: Renogy Core Mini 12V 200Ah LiFePO4 Battery
- Battery Type: Lithium Iron Phosphate (LiFePO4)
- Nominal Voltage: 12.8V
- Capacity: 200Ah
- Energy Capacity: 2560Wh
- Weight: 42.44 lbs (19.25 kg)
- Dimensions: 15.12 × 7.64 × 9.96 in
- Continuous Discharge: 200A
- Peak Discharge: 380A (10 seconds)
- Charging Current: Up to 100A
- BMS: 200A Smart Battery Management System
- Cycle Life: 5000+ cycles @ 80% DOD
- Temperature Range: -4°F to 149°F (charging cut-off below 32°F)
- Protection Rating: IP65 (dust & water resistant)
- Expandable: Up to 4S4P (40.96kWh system capacity)
- Monitoring: Compatible with Renogy 300A shunt (app monitoring support)
- Warranty: 5 Years
Shipping
Orders are processed within 1-3 business days. Delivery typically takes 7-14 business days for domestic orders and 10-20 days for international shipments. Tracking information will be provided once your order ships.
1 / 1
Ships from: CAN
Recently Viewed
You haven't viewed any products yet.
Frequently Asked Questions
What should I look for in a compact 12V lithium battery for RV, van, marine, or off-grid solar use?
A good compact 12V lithium battery should balance usable capacity, cold-weather protection, discharge power, cycle life, and physical size. For many RV, van, boat, and solar storage setups, lithium iron phosphate is preferred because it is lighter than many lead-acid options, offers deeper usable capacity, and typically lasts much longer.
The Renogy Core Mini 12V 200Ah is a strong fit when space is limited but energy needs are still high. It provides 200Ah or 2560Wh in a relatively compact case measuring 15.12 × 7.64 × 9.96 inches, with a weight of 42.44 pounds. It also includes a 200A smart BMS, supports up to 200A continuous discharge, and can handle up to 380A peak for 10 seconds, which matters for demanding 12V loads.
It is especially useful for shoppers who need reliable battery storage for fridges, lights, inverters, fans, or mobile work setups. A key buying point is its 5,000+ cycle life at 80% depth of discharge. The main tradeoff is that charging is protected below 32°F, so users in freezing conditions need a charging strategy even though the battery can operate in very cold environments.
Is a 200Ah LiFePO4 battery better than lead-acid for home backup, camping, or off-grid power?
For most modern backup and off-grid setups, a 200Ah LiFePO4 battery is usually the better choice than lead-acid if you want more usable energy, longer life, and less maintenance. A 12V 200Ah LiFePO4 battery like this one stores 2560Wh and can deliver steady high output while supporting 5,000+ cycles at 80% depth of discharge. In real use, that means more of the battery’s capacity is practical to use regularly compared with many lead-acid batteries, which are often best kept at shallower discharge levels.
This type of battery is a strong option for running essentials such as portable fridges, lights, CPAP machines, routers, laptops, and inverter-powered small appliances in an RV, cabin, boat, or emergency backup system. It also has a smart BMS with over 25 protections, which improves safety and system stability.
The tradeoff is that lithium batteries require compatible charging equipment and cold-weather charging awareness. This battery includes low-temperature charging protection, which helps prevent damage, but users in freezing climates should confirm their charger, solar controller, and installation plan are suitable.
Can this compact cold-weather 12V 200Ah battery run high-demand loads and expand into a larger solar storage system?
Yes, this battery is designed for both high-demand 12V use and system expansion. It supports 200A continuous discharge and up to 380A peak discharge for 10 seconds, which makes it suitable for substantial inverter loads, DC appliances, and energy-hungry mobile or off-grid setups when the rest of the system is sized correctly.
For shoppers planning to grow beyond a single battery, it can be expanded up to 4S4P for as much as 40.96kWh of total system capacity. That makes it useful not only for compact RV or van systems, but also for larger solar storage banks in cabins, marine applications, and backup power installations. It is also IP65 rated for dust and water resistance, which adds durability for mobile and outdoor environments.
This battery is a particularly good fit for users who want a compact footprint without sacrificing output. The main limitation is that system expansion and high-load operation require proper cabling, inverter sizing, charge control, and battery matching. For monitoring, it is compatible with a Renogy 300A shunt for app-supported tracking, which can help users manage performance in larger systems.
