The Renogy Wanderer Li 30A PWM Charge Controller is a compact and reliable solar charging solution designed for 12V off-grid systems. Featuring advanced 4-stage PWM charging, multiple safety protections, and support for AGM, Gel, Flooded, and LiFePO4 batteries, it helps maximize battery performance and lifespan. Ideal for RVs, boats, cabins, and portable solar applications.
Key Features:
- 30A PWM solar charge controller for 12V systems
- Compatible with AGM, Gel, Flooded, and LiFePO4 batteries
- Smart 4-stage charging: Bulk, Boost, Float, and Equalization
- Built-in temperature compensation for improved charging efficiency
- Multiple LED indicators for real-time system status
- Comprehensive protection against overcharge, short circuit, reverse polarity, and overload
- RS232 communication port for optional BT-1 Bluetooth monitoring
- Compact, lightweight, and easy-to-install design
Specifications:
- Model: Renogy Wanderer Li 30A
- Nominal System Voltage: 12 VDC
- Rated Charge Current: 30A
- Maximum PV Input Power: 400W
- Maximum PV Input Voltage: 25 VDC
- Charging Method: PWM (Pulse Width Modulation)
- Battery Compatibility: AGM, Gel, Flooded, LiFePO4
- Temperature Compensation: -3mV/°C/2V
- Self-Consumption: <10mA
- High Voltage Disconnect: 16V
- Boost Duration: 120 Minutes
- Communication Port: RS232
- Bluetooth Compatibility: Renogy BT-1 Module (Sold Separately)
- Maximum Wire Size: 8AWG
- Enclosure Rating: IP20
- Operating Temperature: -20°F to 113°F (-29°C to 45°C)
- Dimensions: 6.45 x 4.31 x 1.76 in
- Weight: 0.65 lbs (0.29 kg)
- Warranty: 1 Year
